⊙ Exceptional Lifting Performance

• Features an 88m eight-section main boom and a standard 18m jib.
• Optional 2×8m extension jibs provide a maximum lifting height of 116m.
• Delivers a maximum lifting moment of 532t·m, with the fully extended boom capable of lifting up to 6.5t.

⊙ Powerful and Versatile Lifting Capabilities

• 29.3m main boom with a 5m width: Lifts 89t effortlessly.
• 88m fully extended boom with a 26m reach: Lifts 6.5t with ease.
• 82.1m main boom + 34m jib with a 60m range: Supports a load of 1.1t.

⊙ Fuel-Efficient and Environmentally Friendly

• Equipped with a Dongkang Non-Stage IV engine, eliminating the need for urea.
• Reduces fuel consumption by over 30%, saving up to 60,000 tons of fuel annually.
• The jib is compatible with 130–200t lifting tasks, ensuring versatile applications.

⊙ Superior Load Handling and Quick Turnaround

• Capable of carrying 29 counterweights + 4 outrigger boxes during transport.
• Handles up to 110t for close-range operations with ease.
• Dual slewing systems and double-row ball slewing bearings provide enhanced stability for heavy loads.

⊙ Reliable and High-Performance Chassis

• Powered by a Weichai WP12 engine paired with a Faster 12-speed transmission.
• Optional 445/80R25 tires deliver exceptional load-bearing capacity.
• Achieves a maximum speed of 80km/h and a climbing grade of up to 45%, ensuring efficient movement on-site and between locations.

⊙ Enhanced Comfort and Convenience

• Air-floating multifunctional driver seat and folding berth for the passenger ensure a comfortable working environment.
• Power seats with armrest box linkage for intuitive operation.
• Remote control functionality enables a single operator to fully extend or retract the crane and support systems, improving efficiency and reducing setup time.
