View larger image
Rated Power：93kW
Delivery Time：
Shipping:
Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee
After-sales Service：1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
Feature
SINOMACH GYA6000L Asphalt Paver
Wheel type pavers are widely used, convenient for quick transition, strong maneuverability and high work efficiency.
Dongfeng Cummins EFI engine, strong power, high reliability; good low temperature start-up performance.
Equipped with full hydraulic automatic telescopic screed, paving width 1.8-4.5m stepless adjustable.
Optional all-wheel drive model provides greater traction for heavy duty and softer roadbed conditions.
Driving tire drive, the paving speed adopts constant speed automatic control technology.
The key hydraulic components such as pumps, motors, joints, etc. are properly matched and can be adapted to the transportation and paving of any stable soil and asphalt mixture.
Parameter
| Engine manufacturer | Cummins |
| Engine Model | QSB 3.9-C125 |
| Rated Power | 93kW |
| Operating weight | 16000kg |
| Overall dimensions | / |
| Basic Pave Width | 2.5m |
| Maximum Pave Width | 6m |
| Maximum Layer Thickness | / |
| Maximum Paving Speed | 0-11m/min |
| Maximum Travel Speed | 0-15km/h |
| Theoretic productivity | / |
| Hopper Capacity | / |
| Gradeability | / |
| Heating of screed | / |
| Travel type | Rear wheel drive |
