XCMG LW500FN Wheel Loader
VS


Bucket Load:2.5~4.5m³

Rated Load:5000kg

Rated Power:162kw


Delivery Time:

In Stock (Within 7 days)
Production (Within15 to 30 days)
Customization (negociated delivery time)

Shipping:

Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee


After-sales Service:1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Share To:

Feature

XCMG LW500FN Wheel Loader




1. XCMG’s exclusive high torque and high efficiency drive chain features reasonable matching.
2. The front frame adopts the box structure with integrally cast lugs and the rear frame adopts the special-shaped box beams welded from variable stiffness bent plates, featuring high carrying capacity.
3. The hinged joints between front and rear frames adopt the structure of rolling bearings + knuckle bearings, featuring high carrying capacity and working stability.
4. With short wheelbase and small turning radius, this product features high mobility and flexibility and outstanding field adaptability.
5. The ergonomically design cab adopts integral skeleton structure, delicate interior trim parts, and sound insulation and noise reduction measure, featuring broad visual field, super-large space, and high operation comfort.
6. The diversified configurations and complete attachments comprehensively adapt to the construction needs in different regions and under different working conditions.

Performance Highlights:
The 160kN traction force and ≥3. 5m high dumping capacity handle the severe conditions with ease. ≥7,500kg lifting capacity and 170kN breakout force handle all kinds of materials with ease.

Parameter

Rated operating load5000KG
Bucket capacity2.5~4.5m³
Machine weight16900kg
Dump clearance at maximum lift3150~3560mm
Reach at maximum lift1100~1190mm
Wheel base2960mm
Tread2250mm
Height of hinge at maximum lift height4112mm
Working height(fully lifted)5510mm
Max.breakout force170kn
Rated Power162KW
Gradeability28%
