XCMG XD133 Tandem Roller

Home Product Roller/Compactor Double Drum Roller

View larger image

XCMG XD133 Tandem Roller

Features

Engine Model：Cummins QSB4.5-C160-30

Operating Weight： 13000Kg
Axle Load Front：6500Kg

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 30 days)

Customization (negociated delivery time)

Shipping:

Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee

After-sales Service：1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Chat Now

Message E-mail ：info@machplaza.com

Share To:

Feature Parameter Brochure

Feature

XCMG XD113 Tandem Roller

XD133 Vibratory roller is a type of asphalt compaction machinery product which is independently researched and developed by XCMG Road Machinery Business Unit based on decades of experience in compaction machinery research and development. It is designed for the compaction of asphalt pavement, asphalt layer of different materials and different thickness, especially suitable for roads, parking lots, airports and other large engineering projects, can also be used for compaction of roadbed and sub-base material, wide application scope.

Parameter

Operating weight	13000Kg
Axle load, front	6500Kg
Axle load, rear	6500Kg
Static linear load	299N/cm
Engine manufacturer	Cummins
Engine Model	QSB4.5-C160-30
Rated Power	119Kw/rpm
Speed range (1)(2)(3)	0-6/0-12/-km/h
Vibration frequency	45/55Hz
Vibration amplitude	0.80/0.35mm
Centrifugal force	150/95kN
Working width	2130mm
Max. gradeability	35%
Track radius, out	4800/6930mm
Overall dimensions	5146×2336×3076mm
