XCMG XE135F Forestry Excavator

Home Product Special Excavator Excavator

View larger image

XCMG XE135F Forestry Excavator

Bucket capacity：0.32-0.61m³

Engine Model：Cammins

Rated power/speed：86kw/2200r/min

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 30 days)

Customization (negociated delivery time)

Shipping:

Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee

After-sales Service：1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Chat Now

Message E-mail ：info@machplaza.com

Share To:

Feature Parameter Brochure

Feature

XCMG XE135F Forestry Excavator

Supplementary Pontoons and Spuds (Optional)

– Supplementary pontoons can be added on each side to boost stability in deeper water operation.- Spud piles attach to supplementary pontoons help to overcome buoyancy effect, it offers added stability and enhanced operability.

Non Hydraulic Extendable Amphibious (Standard)

– For non hydraulic extendable design, there are 2 separate locking pin positions for each pontoon on the horizontal mounting beams.- Users can choose their desired overall track width during the installation process.

HydraulIc Extendable Amphibious & Retractable Pontoons (Optional)

– Designed for ease of land transportation of complete machine by trailer when pontoons are fully retracte.- Higher ROI through long term saving of manpower, crane hiring and other logistical cost.

High Strength Polymer Shoe

– Polymer track shoe can absorb shock from outter impact because it is more resilient than steel.- Surface of polymer shoe is harder than steel, so it is free from wearing and rust.

Parameter

Operating weight	13200kg
Bucket capacity	0.32-0.61m³
Engine Model	Cammins
Rated power/speed	86kw/2200r/min
Maximum torque/speed	470N.m/1300rpm
Travel speed（H/L）	3.8km/h
Swing speed	11r/min
Displacement	3.8L
Bucket digging force	99.1KN
Arm digging force	68KN
