XCMG XGS58 Telescopic Boom Lift
VS


Max. Working Height:58.6m

Max. Platform Height:56.6m

Max. working range:25.1m


Delivery Time:

In Stock (Within 7 days)
Production (Within15 to 30 days)
Customization (negociated delivery time)

Shipping:

Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee


After-sales Service:1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees

Share To:

Feature

XCMG XGS58 Telescopic Boom Lift


XCMG XG Series Aerial Work Platform:

The XCMG XG Series aerial work platforms include a range of models such as scissor lifts, articulated boom lifts, and telescopic boom lifts. The XGS series of telescopic boom lifts spans heights from 22 meters to 58 meters, offering a combination of expansive working space, safety, high efficiency, and energy savings. Known for their precise and stable operation, these platforms are widely used across a variety of aerial tasks.

XCMG Aerial Work Platform XGS58 – Scope of Application:

The XGS58 model is ideal for high-altitude tasks such as material handling, pipe installation, application of coatings, fireproofing, painting, and the installation of elastic pillars. It reduces the need for scaffold construction and disassembly, enables three-dimensional cross-construction, lowers overall construction costs, and enhances operational efficiency.

XCMG Aerial Work Platform XGS58 – Key Highlights:

  1. Working Height & Load Capacity: The XGS58 offers a working height of up to 58 meters and a maximum load capacity of 230/450 kg. The dual-load control system automatically adjusts the working range based on the load, accommodating a wide variety of user needs.
  2. Versatile Boom Configuration: The platform is equipped with three telescopic booms, a tower boom, and a small flying boom, allowing for obstacle navigation and a broad operational range.
  3. Precise Hydraulic System: The sensitive hydraulic system provides precise control for enhanced accuracy in operation.
  4. Comprehensive Safety Features: Multiple safety designs are integrated into the platform to ensure the protection of both operators and the equipment during use.

Parameter

Max. Working Height58.6m
Max. Platform Height56.6m
Max. Working Range25.1m
Max. Load Capacity230kg
Boom Luffing Range-1~ +80°
Rotation Angle of Turntable360°
Rotation Angle of Platform/
Max. Tail Wagging2.32m
Max. Travel Speed4.5km/h
Min. Turning Radius9.5/6.6m
Min. Ground Clearance/
Max. Grade Ability45%
Tire Specification445/50D710 24-ply
Engine ModelDeutz TCD3.6 L4
Rated Power of Engine74.4kw/(2300)(r/min)
Total Weight27200kg
Platform Size/
Overall Length19.45m
Overall Width2.49m
Overall Height3.05m
Wheel Base5.22m
