Feature
XGMA XG6281F Road Roller
It is widely used for compaction of ground or asphalt pavement in town roads, stadiums, municipalities and other small projects, compaction of small foundations and sub-foundations, sand and gravel materials. The frame of the truck adopts the frame-less structure of fork and foot, thus it has very good edge performance and shows its unique superiority in the compaction of road shoulder and trench foundation.
The advanced technology adopts hydraulic transmission, hydraulic vibration and steering, and the main parts and components are made of international brands with high reliability and leading performance parameters. Adopting front and rear frame articulated structure, flexible steering and good stability. Front and rear wheels double drive, stepless speed change, strong climbing ability, superior walking performance, good compaction surface flatness. Single wheel vibration work is optional. The front and rear wheels are equipped with mud scraping and sprinkling devices, with electric sprinkling function. Hydraulic pipeline arrangement is reasonable and neat, XG6033D metal cover shell, equipped with roll-over protection frame, beautiful appearance.
Convenient manoeuvring and large ground clearance of both side racks make it easy to see both edges of the steel wheels during construction, and it is easy to complete the roadside compaction work. XG6033D can achieve forward, backward and stop by one lever; the vibration start-stop control is electromagnetic control; the steering system adopts full hydraulic steering technology, which makes the steering operation light and dexterous; XG6033D front and rear steel wheels’ wheel side drive device with normally closed multi-plate wet brake, and hydrostatic closed drive system ensures the safety performance of driving.
Parameter
working quality | 28000kg |
Front wheel distribution mass | 14000 |
compaction wheel width (front wheel/rear wheel mm) | 1130/900 |
Compaction wheel diameter | 1700 |
Climbing capacity | 100 |
maximum lifting height of push shovel | 1000 |
Engine model | 上柴SC11CB255G2B1(C6121ZG16c) |
rated power | 187kw |
External dimension | 7495X3650X3625mm |
