ZOOMLION FD60Z Interal Combustion Forklift
VS


Min. Turning Radius:3320-3507 mm

Max. Lifting Speed(loaded/empty):350/450 mm/s

Max. Lifting Height:7000 mm

Rated Capacity:5000-7000 kg


Delivery Time:

In Stock (Within 7 days)
Production (Within15 to 30 days)
Customization (negociated delivery time)

Shipping:

Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee


After-sales Service:1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees

Share To:

Feature

ZOOMLION FD60Z Interal Combustion Forklift


It can be equipped with Japanese engine, with strong power and low failure rate.

Spacious driving space. USB cigarette lighter and charging port are optional for outdoor operation.

Conical design is adopted for pipe joints to prevent oil leakage.

Reinforced mast with wide view design improves efficiency and safety;

Engine is with large torque and capacity, which is powerful and can meet different operation demands;

Lifting system is equipped with up and down buffer cylinders, which reduce shock and vibration efficiently;

Parameter

Rated capacity6000Kg
Load centre600mm
Lifting height3000mm
Free lifting height208mm
Tilting angle6°/12°
Turning radius3507mm
Front overhang615mm
Tread335mm
Wheelbase2340m
Fork spread(Min./Max.)-
Working aisle width with pallet(Ast)-
Service weight-
Operating pressure for attachment20MPa
Travel (Laden)26Km/h
Travel(Unladen)30Km/h
Lifting(Laden)460mm/s
Lifting(Unladen)485mm/s
Lowering (Laden)400mm/s
Lowering(Unladen)350mm/s
Laden0.2
Driven motor-
Battery-
Rear Wheel8.25-15-14PR
Front Wheel8.25-15-14PR
Overall Dimension(L×H×W)3547×2000×2500
Weight8640kg
