ZOOMLION FD70Z Interal Combustion Forklift
VS


Min. Turning Radius:3320-3507 mm

Max. Lifting Speed(loaded/empty):350/450 mm/s

Max. Lifting Height:7000 mm

Rated Capacity:5000-7000 kg


Delivery Time:

In Stock (Within 7 days)
Production (Within15 to 30 days)
Customization (negociated delivery time)

Shipping:

Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee


After-sales Service:1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees

Share To:

Feature

ZOOMLION FD70Z Interal Combustion Forklift


The ZOOMLION FD70Z IC forklift is a high-performance material handling solution designed for demanding industrial environments. This forklift has a rugged structure, advanced features, and high efficiency and reliability, making it ideal for warehouses, manufacturing plants, and construction sites.

Key Features and Specifications:
1. Engine:
Type: Internal Combustion (Diesel)
Torque: Provides high torque for greater lifting capacity and faster operation. The powerful diesel engine ensures high fuel efficiency while providing powerful acceleration and lifting power for heavy loads.
2. Load Capacity:
Rated Load: 7,000 kg The FD70Z is designed to handle large loads with ease, making it ideal for heavy-duty applications and transporting large materials.
3. Lift Height:
Maximum Lift Height: 3,300 mm
Mast Type: Dual or Triple Mast Options The forklift is designed with a variety of lift capacities, allowing operators to efficiently stack and retrieve goods in high storage environments.
4. Mobile:
Turning radius: 3,300 mm The compact design and impressive turning radius facilitate easy maneuvering in tight spaces such as warehouses or narrow aisles in busy workplaces.
5. Comfort and safety:
Safety features: Equipped with automatic parking brake, seat belts and protective overhead guards to ensure operator safety. These features promote a safe working environment and reduce the risk of accidents during operation.
6. Durability:
Structure: The FD70Z is designed to last, providing reliable performance while minimizing maintenance requirements.

Parameter

Rated capacity7000Kg
Load centre600mm
Lifting height3000mm
Free lifting height218mm
Tilting angle6°/12°
Turning radius3507mm
Front overhang625mm
Tread335mm
Wheelbase2340m
Fork spread(Min./Max.)-
Working aisle width with pallet(Ast)-
Service weight-
Operating pressure for attachment20MPa
Travel (Laden)26Km/h
Travel(Unladen)30Km/h
Lifting(Laden)460mm/s
Lifting(Unladen)485mm/s
Lowering (Laden)450mm/s
Lowering(Unladen)400mm/s
Laden0.2
Driven motor-
Battery-
Rear Wheel8.25-15-14PR
Front Wheel8.25-15-14PR
Overall Dimension(L×H×W)3557×2000×2500
Weight9340kg
