ZOOMLION HZS180E Concrete Mixing Plant

Home Product Concrete Mixing Plant Concrete Machinery

View larger image

Theoretical rated output：200m³/h

Discharge height：3.8m

Total power ：205kw

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 30 days)

Customization (negociated delivery time)

Shipping:

Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee

After-sales Service：1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Chat Now

Message E-mail ：info@machplaza.com

Share To:

Feature Parameter Brochure

Feature

ZOOMLION HZS180E Concrete Mixing Plants

HZS series concrete batching plant with twin shaft forced mixing concrete mixer is very popular in all the countries and regions. It is stationary with two main types. One is skipping hopper feeding and the other one is belt conveyor feeding.
Skip hopper feeding type has the advantages of small area, easy to install and remove. Its price is cheaper and easy to maintain.
Belt conveyor feeding type covers a bigger area and has a very high efficiency of concrete mixing, which is the ideal machine for concrete selling, and big construction such as skyscraper, road and bridge.

Parameter

Theoretical rated output	200m³/h
Discharge height	3.8m
Mixer	JS3000D
Theoretical producting periods	60S
Aggregate storage	4×25m³
Max. weighing value of slant belt conveyor	600kg
The conveying capacity of screw conveyor	100t/h
Total power	205kw
Batching range and accuracy of aggregate	/
