ZOOMLION ZS0607HD Scissor Lift
VS


Work Height:7.8 m

Platform Extension:0.91 m

Overall Height (Rails Down):1.79 m

Platform Capacity:230 kg


Delivery Time:

In Stock (Within 7 days)
Production (Within15 to 30 days)
Customization (negociated delivery time)

Shipping:

Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee


After-sales Service:1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees

Share To:

Feature

ZOOMLION ZS0607HD Scissor Lift


Hydraulic scissor-type aerial working platforms cover a height of 4-14 metres and can be widely used in building construction, plant construction, house decoration and maintenance. The products are driven by hydraulic motors and have excellent performance such as low centre of gravity, stable operation, large platform load and adaptability to harsh working conditions.



Intelligent Interconnection

Zoomlion Hi-Tech’s intelligent remote monitoring and rental management platform makes it easy to access the status of equipment (location, working condition information and abnormal warning, etc.) for effective operation management.

Flexible and smooth hydraulic drive

Optimised matching of electrical and hydraulic design, the number of Hud cycles is 20% higher than the counterparts, providing long-lasting endurance.

Precise control greatly improves the smoothness of movement.

Ground clearance is greater than 10% of the industry, providing better durability.

Low Cost of Ownership

Universal and modularised design of parts, easy maintenance.

Integral screw-out trays on both sides, convenient for overhauling and service.

Durable, safe and reliable.

Parameter

Max. working height7.8m
A - Platform Height-Elevated5.8m
B - Platform Height-Stowed1.05m
C - Platform Length1.65m
D - Platform Width0.74m
Platform Extension0.91m
E - Overall Height (Rails Up)2.20m
Overall Height (Rails Down)1.79m
F Overall length1.85m
G - Overall Width0.76m
H - Wheelbase1.37m
I - Ground Clearance (Stowed)0.06m
J - Ground Clearance (Raised)0.016m
Rated load230kg
Extended platform safe workloads113kg
Max.number of workers2
Travelling speed (collection status)3.5km/h
Travelling speed (lifting condition)0.8km/h
Turning radius - inside0.1m
Turning radius - outside1.6m
Lifting motor24V
Drive motor3.3KW
Rise/fall time20s/24s
Max. Climbing Capacity25%(14°)
Max. working angle (lateral/longitudinal)1.5°/3°
containmentproportional control
drive (vehicle wheel)dual rear wheels
Multi-disc brakedual rear wheels
tyres∅305mmx114mm
accumulators4x6V/210Ah
battery level/
Charger (optional)24V/30A
Weight1425kg
