Load capacity： 545kg
Load capacity of extended platform ：227kg
Max.Occupant Capacity：4
Delivery Time：
Shipping:
Contact customer service to negotiate shipping details, Enjoy On-time Dispatch Guarantee
After-sales Service：1. Online service: samples, technical specifications, operation manuals, spare parts purchase. 2. Video service: application guidance, troubleshooting and maintenance guidance. 3. Overseas service: MachPlaza has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees
Feature
SUNWARD SWSL2023RT Scissor Lift
SWSL2023RT proportional control handle, any speed control lifting speed and travel speed. Full height travel and steering, convenient operation, improve efficiency.
Parameter
| Load capacity | 545kg |
| Load capacity of extended platform | 227kg |
| Max.Occupant Capacity | 4 |
| Max.Working height | 20m |
| Max.Platform height | 18m |
| Overall length（no ladder） | 5.33m |
| Overall width | 2.39m |
| Overall height（platform folded） | / |
| Working platform dimension（Length x Width） | 7.53m×1.9m |
| Length of extension platform | 0.6m |
| Min.ground clearance（pit protector rising/descending） | 0.017m |
| Wheel base | 1.05m |
| Min.turning radius（inner/outer wheel） | 2.08m/5.3m |
| Lifting motor(kW) | / |
| Max.Traveling speed at low level | 0.6km/h |
| Max.Traveling speed at high level | 7.2km/h |
| Lifting/Descending duration of platform | 65s/59s |
| Max.gradeability | 40% |
| Max. Inclination（side/forward and backward） | 2°/3° |
| Battery(v/Ah) | / |
| Charger(v/A) | / |
| Tire specification | / |
| Total machine weight | 10380kg |
