XGMA XG808F Crawler Excavator

1. Appearance:

The opening of the engine hood increases the ventilation area. The shape of the opening of the side door echoes the shape of the opening of the rear hood, and also increases the heat dissipation area. The maintenance space is also larger than the original model, and maintenance is very convenient.

2. Engine system:

Equipped with Kubota 2607T turbocharged engine with National III emission, power 42.4KW; 8Kw larger than the original model, maximum output torque 226Nm, increased reserve power and reserve torque. The engine displacement is about 2.6L, 0.4L smaller than the original XG806 displacement, and more fuel-efficient.

3. Hydraulic system:

Equipped with Rexroth hydraulic main pump and main valve system, the working pressure is increased from 21.6Mpa to 24.5Mpa, the digging force reaches 45KN, 8KN larger than the original XG806 machine, good operation coordination, better for hard soil operations. Adding a walking pilot valve improves the comfort of walking operation. The rotation speed is 10rpm, which is 17% higher than the original XG806. The travel torque is 4.5/2.5KM/h, which is nearly 25% higher than the XG806.

4. Electrical system:

Color instrument electronic throttle system, equipped with automatic idle fuel saving mode function. Humanized configuration of timer, cigarette lighter, and spare socket for mobile phone charging. The whole vehicle wiring harness adopts imported connectors, which has shockproof and waterproof functions.

Performance summary: high operating efficiency, good operability, low working fuel consumption, digging force and travel traction are greater than the same tonnage models in the industry, very suitable for construction in agriculture, forestry and other fields.
